NGK Spark Plug for Husqvarna CR125 1998-2015

NGK have over 80 years of experience in spark plug manufacturing and are the world leader in spark plug technology. NGK has an extensive range of spark plugs each with their own unique characteristics specifically engineered to its application and designed to suit a broad range of motorcycles ATVs & UTVs in Australasia. With NGK's dedication to quality outstanding reliability and state of the art manufacturing techniques you can rely on your NGK Spark Plugs.

Don’t just ask for a spark plug insist on NGK.

Spark plugs used for racing must withstand especially hard stresses. The speeds during a race are frequently in excess of 10 000 rpm. Temperature pressure and vibrations in the combustion chamber are so immense that conventional ground electrodes could break or melt. For this reason racing spark plugs often come with specially designed ground electrodes the most extreme form with a ring-shaped ground electrode. The spark jumps from the middle electrode to the ring-shaped ground electrode.

Shell

• Thread Size: 14mm
• Thread Pitch: 1.25mm
• Seat Type: Gasket
• Resistor Value: 5K Ohm
• Reach: 19mm (3/4 )
• Hex Size: 21mm (13/16 )
• Terminal Type: Removable Nut
• Overall Height: ISO
• Gap: 0.6mm (0.024 )

Centre Electrode

• Material: Nickel
• Type: Fine Wire
• Size: 1.3mm
• Projection: Non-Projected

Ground Electrode

• Material: Nickel
• Type: Standard
• Quantity: 1

Specifications

• Heat Range: 9
• Resistor: Yes

Bike Fitment:

• Husqvarna CR125 1998
• Husqvarna CR125 1999
• Husqvarna CR125 2000
• Husqvarna CR125 2001
• Husqvarna CR125 2002
• Husqvarna CR125 2003
• Husqvarna CR125 2004
• Husqvarna CR125 2005
• Husqvarna CR125 2006
• Husqvarna CR125 2007
• Husqvarna CR125 2008
• Husqvarna CR125 2009
• Husqvarna CR125 2010
• Husqvarna CR125 2011
• Husqvarna CR125 2012
• Husqvarna CR125 2013
• Husqvarna CR125 2014
• Husqvarna CR125 2015
