NGK Spark Plug for Yamaha TTR125 LWE Big Wheel 2005-2025

NGK have over 80 years of experience in spark plug manufacturing and are the world leader in spark plug technology. NGK has an extensive range of spark plugs each with their own unique characteristics specifically engineered to its application and designed to suit a broad range of motorcycles ATVs & UTVs in Australasia. With NGK's dedication to quality outstanding reliability and state of the art manufacturing techniques you can rely on your NGK Spark Plugs.

Don’t just ask for a spark plug insist on NGK.

The 98% pure copper core delivers increased heat dissipation for more reliable starts and reduced risk of overheating. While cold-rolled threads prevent cross-threading and damage to cylinder heads and a trivalent plating eliminates the need for anti-seize. Complete with a high-grade alumina silicate ceramic.

Shell

• Thread Size: 10mm
• Thread Pitch: 1.0mm
• Seat Type: Gasket
• Resistor Value: 5K Ohm
• Reach: 12.7mm (1/2 )
• Hex Size: 16mm (5/8 )
• Terminal Type: Threaded Stud
• Overall Height: ISO
• Gap: 0.7mm (0.028 )

Centre Electrode

• Material: Nickel
• Type: Standard
• Size: 2.5mm
• Projection: Non-Projected

Ground Electrode

• Material: Nickel
• Type: Standard
• Quantity: 1

Specifications

• Heat Range: 7

Bike Fitment:

• Yamaha TTR125 LWE Big Wheel 2005
• Yamaha TTR125 LWE Big Wheel 2006
• Yamaha TTR125 LWE Big Wheel 2007
• Yamaha TTR125 LWE Big Wheel 2008
• Yamaha TTR125 LWE Big Wheel 2009
• Yamaha TTR125 LWE Big Wheel 2010
• Yamaha TTR125 LWE Big Wheel 2011
• Yamaha TTR125 LWE Big Wheel 2012
• Yamaha TTR125 LWE Big Wheel 2013
• Yamaha TTR125 LWE Big Wheel 2014
• Yamaha TTR125 LWE Big Wheel 2015
• Yamaha TTR125 LWE Big Wheel 2016
• Yamaha TTR125 LWE Big Wheel 2017
• Yamaha TTR125 LWE Big Wheel 2018
• Yamaha TTR125 LWE Big Wheel 2019
• Yamaha TTR125 LWE Big Wheel 2020
• Yamaha TTR125 LWE Big Wheel 2021
• Yamaha TTR125 LWE Big Wheel 2022
• Yamaha TTR125 LWE Big Wheel 2023
• Yamaha TTR125 LWE Big Wheel 2024
• Yamaha TTR125 LWE Big Wheel 2025
